Amada Bending Thick Board Tool / metal bend tool
The straight blade size: 175*37*835mm, 60degree. the material is 42CrMo4, hardness is HRC47+/-3，the weight is 34.5kg. We can make induction harden or all body heat treatment for customers. For the segments size, we can make it according to the customer's requirements. if no request , we will make 835mm standard segments size for you,100L,10,15,20,40,50,200,300,100R.

Hot Tags : Thick board punching tool Amada Thick board upper mold standard press brake punch Straight sword right-angle bending standard upper punch Amada Thick board punch Amada Thick board press brake tooling
Read More
30 degree Amada style press brake punch
The punch size is 134*26*835mm, 30degree,standard sharp blade. the weight is 13.2kg/pcs and we can make 35degree,45degree or other degree according to your request.

Hot Tags : Bend Tool 30 degree Amada style press brake punch standard press brake punch Amada metal bend tool 30 degree press brake punch Amada press brake tooling
Read More
Press brake gooseneck upper tools
The gooseneck punch size: 215*95*835mm, 85degree. the material is 42CrMo4, hardness is HRC47+/-3, and height 215mm, width 95mm, the weight is 42kg. Can be made according to customer's request.

Hot Tags : press brake gooseneck punch Amada press brake tooling Amada gooseneck press brake tooling press brake upper tools 88degree press brake upper tools Gooseneck punch
Read More
Straight sword right-angle bending standard upper punch
This is standard press brake punch, usually the height is 120 and 125mm. The material is 42CrMo / C45 and we can make induction harden or all body heat treatment for customers. For the segments size, we can make it according to the customer's requirements. if no request , we will make 835mm standard segments size for you,100L,10,15,20,40,50,200,300,100R.

Hot Tags : Amada Tools sheet metal forming standard press brake punch Straight sword right-angle bending standard upper punch Amada upper mold customization options cnc press brake tooling
Read More
Custom Precision Press Brake Dies OEM Sheet Metal Bending Solutions
The punch size: 110*26*835mm, 60degree. the material is 42CrMo4, hardness is HRC47+/-3, and height 110mm, the weight is 9kg. Can be made according to customer's request.

Hot Tags : OEM Sheet Metal Bending Solutions Custom Precision Press Brake Dies OEM & ODM Service | Sheet Metal Press brake tooling metal bend tool OEM & ODM Press Brake Punch and Die Sets Bending tool
Read More
European Amada Press Brake Gooseneck Punch 115mm Tooling with Best Price and Quality
The gooseneck punch size: 115*45*835mm, 85degree. the material is 42CrMo4, hardness is HRC47+/-3, and height 130mm, the weight is 12.8kg. Can be made according to customer's request.

Hot Tags : Standard press brake gooseneck punch Amada Gooseneck Press Brake Dies Tooling Amada gooseneck press brake tooling metal bend tool 60degree press brake upper tools Bending tool
Read More
China Good Quality Gooseneck Press Brake Dies Tooling
The gooseneck punch size: 160*56*835mm, 85degree. the material is 42CrMo4, hardness is HRC47+/-3, and height 130mm, the weight is 22.4kg. Can be made according to customer's request.

Hot Tags : Standard press brake gooseneck punch Amada Gooseneck Press Brake Dies Tooling Amada gooseneck press brake tooling metal bend tool 60degree press brake upper tools Bending tool
Read More
Standard press brake gooseneck upper tools
The gooseneck punch size: 120*56*835mm, 85degree. the material is 42CrMo4, hardness is HRC47+/-3, and height 120mm, the weight is 21kg. Can be made according to customer's request.

Hot Tags : Standard press brake gooseneck punch Amada press brake upper tools Amada gooseneck press brake tooling metal bend tool 88degree press brake upper tools press brake punch and die set
Read More
Reverse press brake gooseneck upper tool
The gooseneck punch size: 135*68*835mm, 85degree. the material is 42CrMo4, hardness is HRC47+/-3, and height 135mm, the weight is 23.8kg. Can be made according to customer's request.

Hot Tags : Standard reverse press brake gooseneck punch Amada press brake tooling Amada reverse gooseneck press brake tooling metal bend tool Reverse press brake gooseneck upper tool gooseneck upper tool
Read More
Standard 835mm Segments Press Brake Tooling
This is standard press brake punch,usually the height is 65 and 67mm.the material is 42CrMo / C45 and we can make induction harden or all body heat treatment for customers. For the segments size, we can make it according to the customer's requirements. if no request , we will make 835mm standard segments size for you：100L,10,15,20,40,50,200,300,100R.

Hot Tags : bending machine press brake punch Amada punch Sheet metal fabrication using Amada punch Standard 835mm segments press brake tooling bending machine dies standard press brake punch Durable 42CrMo4 press brake tools
Read More
42CrMo4 material press brake upper tools for 125t machine
The straight blade size: 97*26*835mm,85degree. the material is 42CrMo4, hardness is HRC47+/-3, the weight is 11.1kg.

Hot Tags : Amada press brake tooling press brake punch and die set Sheet metal fabrication using Amada punch Punch and die configurations for bending Amada upper mold customization options Durable 42CrMo4 press brake tools
Read More
Offset Bending Tools / bending tools
Heavy duty press brake tools can bend very thick, high-strength matal plate. Welcome to explore our quality press brake tooling and contact us for professional service! ADVANTAGES Production in two or three strokes Reducing of marks through spring loaded hold-down-device Active components are hardened High repeatability through integrated backgauge Functional test and adjustment through test bends - with your sample sheets SUITABLE FOR Material thickness up to 4,0 mm minimum inside Ø: 2,5 mm x material thickness for steel and aluminium 3,0 mm x material thickness for stainless steel Other shapes and layouts are manufactured individually according to your specifications
