EHT press brake tooling is a matching tool designed specifically for EHT brand CNC bending machines. It has the characteristics of high precision, wear resistance, and strong adaptability, and is widely used in the field of sheet metal processing.
We can customize comprehensive punch and dies, and European EHT tooling. This cnc punch press tooling includes punches, dies, adapters. It supports segmented, solid length, and half-length sizes. we have a wide range of EHT press brake punch and die selections. EHT tooling can deliver a quick, easy, and flexible job with advanced designs.
Tooling system :
JM - System EHTArt.No. :
JM - 16510Brand :
JaminnarOrder(MOQ) :
1Payment :
T/T, Western Union, Alipay, WeChat etc.Product Origin :
MaanshanShipping Port :
Shanghai / Guangzhou or OtherLead Time :
15 - 20 days after receiving the depositAngle :
78°Radius :
1.0mmTotal Height :
220mmMax load :
550 kN/mMaterial :
42CrMo4Hardness :
HRC47±3 / HRC57±3Clamping System :
EHTHeat Treatment :
Full body heat treatment / Laser hardeningSurface Color & Surface Treatment :
Silver / Black / Sandblasting
Jaminnar is in the field of sheet metal processing, and is engaged in the production and sale of bending tools and crowning tables. Jaminnar can supply punches and dies for any type of press brake. These tools are made of hardened and ground high quality steels C45 and 42CrMo. Our product range includes tool types such as: Amada / promecam european, Trumpf / Wila, Bystronic/Beyeler, LVD type, EHT type, American type, Gasparini Type, Colgar Type，Colly Type，Ajial-Axial Type, Hämmerle-bystronic Type, Special tools, Shear blades, Crowning Table, Rolla-V, Adjustable Die, Custom Rotary Dies, Clamping system, Tools Storage Cabinets, Protective Traceless Film, etc. Jaminnar has two in-house R&D department specializing in designing technologically advanced solutions and focuses on innovative solutions, with the support of our technical department we are able to design and supply special punches and dies and research the right solution for your bending project. The tools - our company supplies for press brakes are efficient and durable, thanks to the ability to use cutting-edge technology and uses advanced equipment for production with Implement strict quality control and the guarantee of highly qualified employees. Our molds undergo rigorous testing to ensure stability and durability; Reliability and competitive pricing are two other distinguishing features of our bending tools.
|
ART.NO.: JM - 17102 |
|
|
Tooling system |
JM - System EHT |
|
Angle |
78° |
|
Radius |
1mm |
|
Height |
220 mm |
|
Load |
550 kN/m max. |
|
Material |
42CrMo |
Quality And Precision
▶Optimum materials
▶42CrMo4, tempered to 1100- 1200 N/mm²
▶Bending Radius/Intake Radius Hardens to 54 – 60 HRC
▶Precision ground
▶Guaranteed exchangeability and parallelism
▶Tool marking with all technical information
2050 mm Tool Set
▶17 Segments, with Simple Clamp and horn extension left and right
▶ Sectionalized punches/top-tools are delivered as a complete set
▶ Upper punch: 100 (left horn) 45, 50, 55, 60, 65, 70, 75, 80, 85, 90, 175, 250×4,100 (right horn) = 2050mm (set)
2550 mm Tool Set
▶19 Segments, with Simple Clamp and horn extension left and right
▶ Sectionalized punches/top-tools are delivered as a complete set
▶ Upper punch: 100 (left horn) 45, 50, 55, 60, 65, 70, 75, 80, 85, 90, 175, 250×6,100 (right horn) = 2550mm (set)
3050 mm Tool Set
▶ 21 Segments, with Simple Clamp and horn extension left and right
▶ Sectionalized punches/top-tools are delivered as a complete set
▶ Upper punch: 100 (left horn) 45, 50, 55, 60, 65, 70, 75, 80, 85, 90, 175, 250×8,100 (right horn) = 3050mm (set)
3550 mm Tool Set
▶ 23 Segments, with Simple Clamp and horn extension left and right
▶ Sectionalized punches/top-tools are delivered as a complete set
▶ Upper punch: 100 (left horn) 45, 50, 55, 60, 65, 70, 75, 80, 85, 90, 175, 250×10,100 (right horn) = 3550mm (set)
4050 mm Tool Set
▶ 18 Segments, with Simple Clamp and horn extension left and right
▶ Sectionalized punches/top-tools are delivered as a complete set
▶ Upper punch: 100 (left horn) 45, 50, 55, 60, 65, 70, 75, 80, 85, 90, 175, 250×12,100 (right horn) = 4050mm (set)
■ Create your own individual tool lengths set for punches/top tools and dies!
■ In addition to the above standard length, if you need to customize a special length, please explain.
FAQ
1. Q: Are you a factory or trading company? How is you factory production experience?
A: We are a factory. 24years Manufacturing experience. Leading supplier in Maanshan city.
2. Q: Can you put my brand logo on these products?
A: Yes, we can.
3. Q: What is the Minimum Order Quantity (MOQ) for your OEM service?
A: MOQ is 1pcs. Purchase amount not less than $50.
4. Q: When can you ship the products after we make payment?
A: Production time is normally 15-25 days.
5. Q: What materials and processing techniques are used for press brake tooling?
A: Material: 42CrMo4; Full body heat treatment HRC 44-50, CNC laser quenching HRC: 54-60; Surface treatment: silver, black coating or sandblasting
6. Q: How long is the warranty period for your products?
A: Under normal use, the warranty period is 1 year.
7. Q: What payment methods do you support?
A: T/T, Western Union, WeChat etc.
The straight blade size: 175*37*835mm, 60degree. the material is 42CrMo4, hardness is HRC47+/-3，the weight is 34.5kg. We can make induction harden or all body heat treatment for customers. For the segments size, we can make it according to the customer's requirements. if no request , we will make 835mm standard segments size for you,100L,10,15,20,40,50,200,300,100R.
